高压超结MOSFET Super Junction MOSFET

Part Number	VDS(V)	ID(A) 25℃	PD(W) 25℃	RDS(ON)(Ω) VGS=10V Typ.	RDS(ON)(Ω) VGS=10V Max.	Qg(nC) (VGS=10V) Typ.	VGS(V)	VGS(th)(V) Typ.	Package
JMF65R600C	650	8	28	0.52	0.6	14	+/-30	3.5	TO-220F
JMD65R600C	650	8	64	0.52	0.6	13	+/-30	3.5	TO-252
JMF65R380C	650	10.6	31	0.34	0.38	20	+/-30	3.5	TO-220F
JMD65R380C	650	10.6	84	0.34	0.38	20	+/-30	3.5	TO-252
JMF65R280C	650	13.8	33	0.25	0.28	26	+/-30	3.5	TO-220F
JMD65R280C	650	13.8	104	0.250	0.28	23	+/-30	3.5	TO-252
JMF65R190C	650	20	30	0.16	0.19	37	+/-30	3.5	TO-220F
JMF60R130C	600	30	34	0.12	0.12	50	+/-31	3.0	TO-220F
JMD80R650DF	800	8	83	0.55	0.65	12.1	+/-30	3.5	TO-252
JMSL65R030	650	100	735	0.026	0.030	141	30	3.5	TO-247
JMSL65R041	650	78	500	0.036	0.041	139	30	3.5	TO-247
JMSL65R070	650	47	290	0.062	0.07	87	30	3.5	TO-247
JMSF65R070	650	47	37	0.062	0.07	68	30	3.5	TO-220F
JMSL65R099	650	40	278	0.09	0.099	66	30	3.5	TO-247
JMSF65R099	650	40	35	0.09	0.099	66	30	3.5	TO-220F
JMSL65R099	650	40	278	0.09	0.099	66	30	3.0	TO-247
JMSF65R099	650	40	35	0.09	0.099	66	30	3.0	TO-220F
JMSA65R099	650	40	248	0.09	0.099	56	30	3.5	TO-220
JMS8N65R099	650	40	248	0.09	0.099	56	30	3.5	DFN8x8
JMSB65R099	650	40	248	0.09	0.099	56	30	3.5	TO-263
JMSL65R125	650	25	216	0.12	0.125	36	30	3.0	TO-247
JMSA65R125	650	25	216	0.12	0.125	36	30	3.0	TO-220
JMSF65R125	650	25	34	0.12	0.125	36	30	3.0	TO-220F
JMSB65R125	650	25	216	0.12	0.125	36	30	3.0	TO-263
JMSL65R180	650	20	146	0.15	0.18	30	30	3.5	TO-247
JMSA65R180	650	20	146	0.15	0.18	30	30	3.5	TO-220
JMSF65R180	650	20	30	0.15	0.18	30	30	3.5	TO-220F
JMSB65R180	650	20	146	0.15	0.18	30	30	3.5	TO-263
JMSH65R180	650	20	146	0.15	0.18	30	30	3.5	TO-262
JMS8N65R180	650	20	30	0.15	0.18	30	30	3.5	DFN8x8
JMSL65R180	650	20	205	0.15	0.18	39	30	3.5	TO-247
JMSA65R180	650	20	205	0.15	0.18	39	30	3.5	TO-220
JMSF65R180	650	20	34	0.15	0.18	39	30	3.5	TO-220F
JMSB65R180	650	20	205	0.15	0.18	39	30	3.5	TO-263
JMSH65R180	650	20	205	0.15	0.18	39	30	3.5	TO-262
JMSL65R180	650	20	205	0.15	0.18	39	30	3.5	TO-247
JMS8N65R180	650	20	205	0.15	0.18	39	30	3.5	DFN8x8
JMSA65R180	650	20	205	0.15	0.18	39	30	3.5	TO-220
JMSF65R180	650	20	34	0.15	0.18	39	30	3.5	TO-220F
JMSB65R180	650	20	205	0.15	0.18	39	30	3.5	TO-263
JMSH65R180	650	20	205	0.15	0.18	39	30	3.5	TO-262
JMSA65R280	650	15	130	0.25	0.28	19	30	3.5	TO-220
JMSF65R280	650	15	33	0.25	0.28	19	30	3.5	TO-220F
JMSB65R280	650	15	130	0.25	0.28	19	30	3.5	TO-263
JMSD65R280	650	15	130	0.25	0.28	19	30	3.5	TO-252
JMSC65R280	650	15	130	0.25	0.28	19	30	3.5	TO-251
JMS8N65R280	650	15	78	0.24	0.28	19	30	3.5	DFN8x8
JMSN65R280	650	15	78	0.24	0.28	19	30	3.5	DFN5x6
JMSA65R380	650	11	90	0.33	0.38	14.7	30	3.5	TO-220
JMSF65R380	650	11	31	0.33	0.38	14.7	30	3.5	TO-220F
JMSB65R380	650	11	90	0.33	0.38	14.7	30	3.5	TO-263
JMSH65R380	650	11	90	0.33	0.38	14.7	30	3.5	TO-262
JMSD65R380	650	11	90	0.33	0.38	14.7	30	3.5	TO-252
JMSC65R380	650	11	90	0.33	0.38	14.7	30	3.5	TO-251
JMSA65R380	650	11	125	0.34	0.38	23	30	3.5	TO-220
JMSF65R380	650	11	33	0.34	0.38	23	30	3.5	TO-220F
JMSB65R380	650	11	125	0.34	0.38	23	30	3.5	TO-263
JMSH65R380	650	11	125	0.34	0.38	23	30	3.5	TO-262
JMSD65R380	650	11	125	0.34	0.38	23	30	3.5	TO-252
JMSC65R380	650	11	125	0.34	0.38	23	30	3.5	TO-251
JMSA65R380	650	11	125	0.34	0.38	23	30	3.5	TO-220
JMSF65R380	650	11	33	0.34	0.38	23	30	3.5	TO-220F
JMSB65R380	650	11	125	0.34	0.38	23	30	3.5	TO-263
JMSH65R380	650	11	125	0.34	0.38	23	30	3.5	TO-262
JMSD65R380	650	11	125	0.34	0.38	23	30	3.5	TO-252
JMSC65R380	650	11	125	0.34	0.38	23	30	3.5	TO-251
JMSF65R310	650	11	30	0.26	0.31	21.8	30	3.0	TO-220F
JMSD65R310	650	11	63	0.26	0.31	21.8	30	3.0	TO-252
JMSF65R380	650	11	29	0.34	0.38	19.9	30	3.0	TO-220F
JMSD65R380	650	11	113	0.33	0.38	19.9	30	3.0	TO-252
JMSF65R650	650	7	28	0.55	0.65	13.1	30	3.5	TO-220F
JMSD65R650	650	7	63	0.55	0.65	13.1	30	3.5	TO-252
JMSC65R650	650	7	63	0.55	0.65	13.1	30	3.5	TO-251
JMSA65R570	650	7	83	0.49	0.57	15	30	3.5	TO-220
JMSF65R570	650	7	33	0.49	0.57	15	30	3.5	TO-220F
JMSB65R570	650	7	83	0.49	0.57	15	30	3.5	TO-263
JMSH65R570	650	7	83	0.49	0.57	15	30	3.5	TO-262
JMSD65R570	650	7	83	0.49	0.57	15	30	3.5	TO-252
JMSC65R570	650	7	83	0.49	0.57	15	30	3.5	TO-251
JMSF65R760	650	5	29	0.66	0.76	14.7	30	3.5	TO-220F
JMSD65R760	650	5	50	0.66	0.76	14.7	30	3.5	TO-252
JMSF65R950	650	4	25	0.86	0.95	7.6	30	3.5	TO-220F
JMSD65R950	650	4	40	0.86	0.95	7.6	30	3.5	TO-252
JMSC65R950	650	4	40	0.86	0.95	7.6	30	3.5	TO-251
JMSNF65R950	650	4	25	0.86	0.95	7.6	30	3.5	TO-220NF
JMSA65R930	650	4	50	0.82	0.93	13.6	30	3.5	TO-220
JMSF65R930	650	4	33	0.82	0.93	13.6	30	3.5	TO-220F
JMSB65R930	650	4	50	0.82	0.93	13.6	30	3.5	TO-263
JMSH65R930	650	4	50	0.82	0.93	13.6	30	3.5	TO-262
JMSD65R930	650	4	50	0.82	0.93	13.6	30	3.5	TO-252
JMSC65R930	650	4	50	0.82	0.93	13.6	30	3.5	TO-251
JMSD65R1K5	650	3	30	1.23	1.5	5.8	30	3.5	TO-252
JMSD65R1K6	650	3	38	1.35	1.6	10.5	30	3.5	TO-252
JMSC65R1K6	650	3	38	1.35	1.6	10.5	30	3.5	TO-251
JMSD65R2K5	650	2	25	2.20	2.5	9.5	30	3.5	TO-252
JMSC65R2K5	650	2	25	2.20	2.5	9.5	30	3.5	TO-251
JMSL55R050	550	60	290	0.046	0.05	84	30	3.5	TO-247
JMSL55R055	550	60	290	0.05	0.055	84	30	3.0	TO-247
JMSL55R140	550	23	205	0.11	0.14	40	30	3.5	TO-247
JMSF55R140	550	23	34	0.11	0.14	40	30	3.5	TO-220F
JMSB55R140	550	23	205	0.11	0.14	40	30	3.5	TO-263
JMSL55R140	550	23	205	0.11	0.14	40	30	3.5	TO-247
JMSF55R140	550	23	34	0.11	0.14	40	30	3.5	TO-220F
JMSB55R140	550	23	205	0.11	0.14	40	30	3.5	TO-263
JMSF55R290	550	15	33	0.25	0.29	23	30	3.0	TO-220F
JMSD55R290	550	15	125	0.25	0.29	23	30	3.0	TO-252
